Canadian Aircraft Flight Manuals
Manufacturers and operators of aircraft and equipment produce large numbers of manuals for their air and ground crews. These manuals generally cover all phases of operation, from assembling the newly purchased aircraft (Aircraft Erection), operation and maintenance of the equipment, to storage of the equipment. Manuals are revised as new procedures are developed, or modifications made to existing models. We have over 40,000 technical manuals covering aircraft, engines, and other air-related equipment. Most of these manuals were developed and published by the military for their own use from circa 1915 through 1970, with the bulk of the manuals covering World War II aircraft (1940-1945). Unfortunately, sheer volume precludes our making available a complete list of our holdings. In order to find out more about our Technical Manuals, please contact the Archives.
Airplane Flight Manual Standardized in 1975, AFMs are now required in aircraft built and flown after March 1, 1979 No person may operate a civil aircraft without complying with the operating limitations specified in the approved Airplane or Rotorcraft Flight Manual (if applicable), markings, and placards, or as otherwise prescribed by the. Apr 01, 2014 This video from the now defunct Canadian Airlines is a refresher course for flight attendants on the Boeing 747-400. The video goes over emergency procedures on board the aircraft as.
Accessing this collection
A. r. rahman revival (vande mataram). The Canadian Aviation Regulations define two types of ultralight aircraft: basic ultra-light aeroplane (BULA), and advanced ultra-light aeroplane (AULA).
Canadian definition of ultra-light[edit]
Regulation of ultra-light aircraft in Canada is covered by the Canadian Aviation Regulations. An earlier definition[1] of 'ultra-light aeroplane', effective October 10, 1996, meant
- a single-seat aeroplane that has a launch weight of 165 kg (364 pounds) or less, and a wing area, expressed in square metres, of not less than the launch weight in kilograms minus 15, divided by 10, and in no case less than 10 m2,
- a two-seat instructional aeroplane that has a launch weight of 195 kg (430 pounds) or less, and a wing area, expressed in square metres, of not less than 10 m2 and a wing loading of not more than 25 kg/m2 (5.12 lb/ft2), the wing loading being calculated using the launch weight plus the occupant weight of 80 kg (176 pounds) per person, or
- an advanced ultra-light aeroplane;
On June 1, 2003, the definition was amended to state that an 'ultra-light aeroplane' means either an advanced ultra-light aeroplane or a basic ultra-light aeroplane.[2]
Basic ultra-light aeroplane[edit]
On July 6, 1956 the Department of Transport first issued new requirements for ultralight aircraft, a category that was eventually renamed 'Amateur-built aircraft', leaving Canada without an ultralight category. The basic ultralight category was established as a new category in 1982 to fill this gap.[3] Regulation of ultralight aircraft in Canada is covered by the Canadian Aviation Regulations, which defines a 'basic ultra-light aeroplane' as:
an aeroplane having no more than two seats, designed and manufactured to have:
- a maximum take-off weight not exceeding 544 kg (1,200 pounds), and
- a stall speed in the landing configuration (VS0) of 39 knots (45 mph) indicated airspeed, or less, at the maximum take-off weight;[2]
Advanced ultra-light aeroplane[edit]
According to Canadian Aviation Regulations, Part I, Subpart 1, an 'advanced ultra-light aeroplane' means an aeroplane that has a type design that is in compliance with the standards specified in the manual entitled Design Standards for Advanced Ultra-light Aeroplanes (DS10141).[2][4]
An advanced ultra-light aeroplane is an aeroplane which:
- Is propeller driven;
- Is designed to carry a maximum of two persons, including the pilot;
- Has a maximum take-off mass, MTOmax or WTOmax, of:
- 350 kg (770 lb) for a single place aeroplane, or
- 560.0 kg (1232 lb) for a two place aeroplane;
- A maximum stalling speed in the landing configuration, VS0, at manufacturer's recommended maximum take-off mass (weight) not exceeding 72 km/h (20 m/s, 45 mph) (IAS); and
- Is limited to non-aerobatic operations. Non-aerobatic operations include:
- manoeuvres incident to normal flying
- stalls and spins (if approved for type);
- lazy eights, chandelles; and
- steep turns, in which the angle of bank is not more than 60°
The advanced ultra-light aeroplane (AULA) category is similar, but not identical, to the American light sport aircraft (LSA) category. Many aircraft are available as AULAs in Canada and LSAs in the United States.
Murari movie audio songs free download. Movie Name: Murari – (2001) Cast & Crew: Mahesh Babu, Sonali Bindre Music: Manisharma Category: Telugu Movies Murari songs free download Murari movie songs free download Mahesh Babu Murari mp3 songs download 01 – Alanati Ramachandrudu 02 – Andaanike Aadanive 03 – Bangaru Kalla 04 – Bhama Bhama 05 – Cheppamma Cheppamma 06 – Dum Dum Dum.
Minimum useful load[edit]
Advanced ultra-light aeroplanes shall have a minimum useful load, MU or WU computed as follows:
- For a single place aeroplane:
- MU = 80 + 0.3P, in kg; where P is the rated engine(s) power in kilowatts;
- MU = 175 + 0.5P, in lb; where P is the rated engine(s) power in brake horsepower (bhp).
- For a two place aeroplane:
- MU = 160 + 0.3P, in kg; where P is the rated engine(s) power in kW;
- MU = 350 + 0.5P, in lb; where P is the rated engine(s) power in bhp.[5]
Maximum empty mass (weight)[edit]
The maximum empty mass, MEmax, (WEmax) includes all operational equipment that is actually installed in the aeroplane. It includes the mass (weight) of the airframe, powerplant, required equipment, optional and specific equipment, fixed ballast, full engine coolant, hydraulic fluid, and the residual fuel and oil. Hence, the maximum empty mass (weight) = maximum take-off mass (weight) - minimum useful load.[5]
The registration marks for an advanced ultra-light aeroplane after 1997 begin with 'C-Ixxx'. Prior to that date they were C-Fxxx or C-Gxxx.[5]
Operations[edit]
An ultra-light pilot permit, recreational pilot permit, private, commercial or airline transport aeroplane licence issued by Transport Canada, is required in order for a person to operate an ultra-light aeroplane in Canada.[6] Pilots holding a Recreational or higher license may carry a passenger in a two-seat advanced ultra-light aeroplane. Pilots with only an ultra-light permit may not carry a passenger in an advanced ultralight unless they have received a passenger carrying endorsement. Basic ultralights cannot carry passengers unless the passenger is another pilot. Student pilots undergoing training may be carried in basic ultralights.
Canadian Basic and Advanced Ultralights may be flown in the USA if the pilot holds a Recreational Pilot Permit or higher designation. Pilots holding an Ultralight Pilot Permit with instructor rating and who have at least 2 hours of cross country experience may also fly to the US.[7]
Any Canadian Ultralight flying to the US also requires a Special Flight Operations Certificate from the FAA. This is a form the pilot completes which is then valid for 180 days.[8]
Nomenclature[edit]
Officially this category of aircraft are known in Canada as Ultra-light Aeroplanes although in common use the American term Ultralight Airplanes is often used.[2]
